B-5
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Front Axle & Engine
10. Remove the radiator mounting bolts and remove
the radiator.
11. Remove the front bottom grill and bonnet locking
bracket.
12. Disconnect the LH / RH hoses to the power
steering cylinder and plug the hoses to prevent
oil spillage.
13. Remove the propeller shaft guards.
14. Remove the propeller shaft bearing from support
bracket.
To Next Page
