C-26
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Fig. 9
Removing valves
Fig. 7
1. Gear
2. Screw
3. Washer
4. Plate
5. Key
6. Camshaft
7. Tappet
8. Rod
9. Rocker
10. Circlip
11. Washer
12. Screw
13. Nut
14. Arm, rocker
15. Arm, rocker
16. Bush
17. Bracket
18. Nut
19. Washer
20. Shaft
21. Plug
22. Spring
23. Spacer
24. Bracket
25. Pin
26. Lock
27. Cup
28. Spring
29. Washer
30. Set
31. Valve
32. Valve
Manifolds, Cylinder Head & Valves
