Always use the same grade and specified oil as Replacements.
Dispose off the old oil as per local regulations.
Always use the same oil, as using different oils or specifications can cause damage.
Dispose of the old oil as per local regulations.
► CHANGING THE TRANSMISSION OIL
1. Allow the transmission oil to cool.
2. Remove the drain plug from bottom of the transmission and drain the oil.
3. Replace and check the drain plug.
4. Refill the transmission to the correct level on the dipstick with new oil: Qty 14.5ℓ (3.83 US gal)
► CHANGING ENGINE OIL
Park tractor on a level surface, shut-off the engine and
Remove the sump plug & drain oil. Replace and check
the sump plug and refill the engine with oil to the correct
level on the dipstick. 2.2ℓ(0.58 US gallon).
The grade of oil to be used will depend on the
ambient temperature. See page 56.
The tractor is shipped from the factory with 15W-40.
Important
Important
59
Engine Oil Filler
