Model JM-200 JM-204 JM-250 JM-254 JM300A JM304A
Electrical
equipments
and gauges
Ammeter ＋（） -30~0~ 30 A
Oil pressure gauge （）12V 0~0.5 MPa
Water temperature gauge ℃ 12V (40~100)
pressure gauge 0~1.0 MPa
Head lamp ND118-80T , 20/8W 12V
Rear light WD115-2 , 20/8W.12V
Direction light FT12 , 8W.12V
Electric horn DL87-12
Main filling
capacity (L)
Fuel tank 19 19 19 19 24 24
Engine oil sump 5
Front drive axle ─ 4.5 / 6 ── 6 ── 6
Transmission box 11 14 11 14 11 14
Lifter 9 14
Steering gear 0.4
Cooling water 10 or 12
4
