SYMBOL EXPLANATION
WIRE WITH COLOUR OF WIRE
Y-R
Y- BASE COLOUR ; R - TRACER COLOUR
(Refer colour chart for colour codes)
WIRES - NOT JOINED
WIRES - JOINED
SHILEDED WIRE
TWISTED WIRE
>> IC12/17
CONNECTOR
IC12 - CONNECTOR NO
17 - PIN NO IN CONNECTOR 12
EARTH / GROUND
GROUND ON COMPONENT
POWER SOURCE - BATTERY
POWER SOURCE - DC
POWER SOURCE - AC
FUSE WITH RATING & DIRECTION OF FLOW
ELECTRICAL SYMBOLS USED IN WIRING DIAGRAM
Y
-
R
10 A
MAN-00039
Rev1/Sep2008 46
