BODY AIRBAG
SCORPIO
108
Restart the diagnostic tool and establish the communication with Airbag Module.
Select the LID3 tab in the diagnostic tool as shown above.
Read the RHS pretensioner resistance value
The specified range for RHS pretensioner is 2.0 to 3.0 ohms
Is the resistance within the specified range?
YES
Install the new RHS pretensioner assembly
(Refer the repair manual for the installation
procedure.)
No
If the resistance is more than 5.5 ohms GO to SRSL3
If the resistance is less that 1.9 ohms GO to SRSL4
To Next Page
