BODY AIRBAG
SCORPIO
24
Airbag Module Connector:
Harness side
Vehicle Connector Pin Circuit
Scorpio_Airbag_LHD Airbag Module
30 RHS Pretensioner_Positive
7 RHS Pretensioner_Negative
Scorpio_Airbag_RHD Airbag Module
8 RHS Pretensioner_Positive
9 RHS Pretensioner_Negative
ENTER INTO THE PINPOINT TEST
To Next Page
