BODY AIRBAG
SCORPIO
57
CHECK THE LHS PRETENSIONER
POSITIVE LINE FOR ISOLATION FROM
GROUND UPTO IC - FLOOR
SRSG3
Turn the ignition key to OFF position
Disconnect Floor Interconnector
Turn the ignition key to ON position
Measure the voltage between:
(+) Red Probe of Multimeter
Floor Interconnector, Female side
(-) Black Probe of Multimeter
Vehicle Battery
Pin 3 - LHD Negative terminal
Pin 1 - RHD Negative terminal
Is the voltage more than 1.1 V?
YES
Replace the Floor wiring harness and
reactivate the system.
(Refer to Reactivation sheet.)
NO
Replace both the Floor and CCB wiring
harness and reactivate the system.
(Refer to Reactivation sheet.)
