Mahindra XUV500 User Manual

1-21
Quick Start Guide
V102011© Copyright Mahindra & Mahindra Ltd.
Tool Kit and Spare Wheel
76
84 5
3
1
2
The tool kit is located behind
the third row seat near the tail
gate.Open the tailgate. Raise
the tools storage area floor lid
by lifiting the strap.
1. Screw Driver
3. TOW bar
4. PVC tool bag
5. Winch access tool
6. Assembly screw jack
7. Jack operating lever
8. Wheel spanner
2. D E O spanner 10mm x 12mm
Tool Kit
Spare Wheel
Warning Triangle
Spare wheel is located below
the cargo area. It is placed firmly
in place by the winch and cable
mechanism.
Unclip the warning triangle cove
r
clips and remove the warning
triangle from the location as
shown in the adjacent image.
