VENTILATOREN
FR
AP 100/100 B/120/150
SG 100/100 B/120/15
DE
UK
5. Push the AP shuers/SG external grilles
with the ange into the wall sleeve and
screw to the wall with 4 screws. Ensure the
correct posion of the sealing strip. Note
the installaon posion: with Maico leer-
ing on the boom right.
6. AP/SG 100/100 B/120: If necessary, insert
oponal y screen FG into the shuer/the
external grille.
7. AP/SG 100/100 B/120: Press the housing
unit onto the receptacle so that it audibly
engages in the 4 locking tabs.
8. Seal the AP shuers/the SG external grille
to the wall in a manner that is permanently
elasc and weatherproof. Suitable sealing
material (silicon) is to be provided by the
customer.
9. Run funcon test.
7 Cleaning
If necessary, clean the AP shuer/SG external
grille with a dry cloth. Frequency depends on
ambient condions and ancipated impair-
ments.
