To use casters , first, turn the rubber pads on the desk feet counterclockwise to remove them, and then
use the M14 open end wrench to fix the casters on the desk feet.
As shown in the figure, match the two holes of the felt side pocket (Pay attention to the direction) to the
two mounting holes on the side board .
Use the M4 allen wrench , 2 M6*14 hexagon socket round head screws , and 2 M6 nuts to fix the
felt side pocket on the side board.
31
19
19
9
20
16
24
2
29
9
31
M14 Open End Wrench
×
1
Casters Installation
Felt Side Pocket
Installation
20
×2
24
×2
29
×1
M6 Nut
M6*1*14 Hexagon Socket
Round Head Screw
M4 Allen Wrench
16
2
29 20 24
The locking and unlocking of the
casters can be controlled by moving
the buttons on the casters up and
down.
31
19
