Maidesite US-01 - Hook Installation

8 Page
Accessories Installation Instructions
12
24
15
18
23
17
As shown in the picture, first match the hook with the mounting holes on the side board.
Then use the M4 allen wrench , one M6*1*14 hexagon socket round head screw , and one M6 nut to
fix the hook on the side
board.
Hook Installation
1. Fold the cloth drawer bracket along the dotted line.
2. Use a screwdriver and 6 ST4.8*0.8*13 flat head self-tapping screws
to fix the cloth drawer bracket to the desktop along the guide holes on the desktop.
3. Install the cloth drawer into the cloth drawer bracket as shown.
Cloth Drawer Installation
20
M6*1*14 Hexagon Socket
Round Head Screw
×1
29
M4 Allen Wrench
×1
24
M6 Nut
×1
23
ST4.8*0.8*15
×6
20 2429
