4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware
are present before beginning assembly.
(9) 2-1/2” Lag Bolt (10) Large Flat Washer (11) Concrete Anchor (12) Plastic End Cap
(Qty. 4) (Qty. 4+1 extra) (Qty. 4) (Qty. 1)
(13)
Glass Bumper (Qty. 8+1 extra)
4 mm Hex Wrench (Qty. 2)
3/16” Hex Wrench Touch-up Pen Tipping Restraint Hardware Kit (Qty. 1)
(Qty. 1) (Qty. 1) (Inside Plastic Bag)
TV Mounting Kit
M4 x 12 Bolt (Qty. 4) M4 x 30 Bolt (Qty. 4) M5 x 12 Bolt (Qty. 4) M5 x 30 Bolt (Qty. 4)
M6 x 12 Bolt (Qty. 4) M6 x 35 Bolt (Qty. 4) M8 x 16 Bolt (Qty. 4) M8 x 40 Bolt (Qty. 4)
M4 Lock Washer
(Qty. 4)
M5 Lock Washer
(Qty. 4)
M6 Lock Washer
(Qty. 4)
M8 Lock Washer
(Qty. 4)
Large Spacer (Qty. 4) Small Spacer (Qty. 4) M4/M5 Flat Washer (Qty. 8) M6/M8 Flat Washer (Qty. 4)
Tools required: Hex wrench (provided) and Phillips screwdriver (not provided).
