2 Detailed Configuration
Guide
2.1 PC Configuration
To facilitate the user management, the AP integrates the web management
function. Through this function, we can realize various management functions in
a simple mode to facilitate using. When the user configures the hardware, the
user can use the PC to configure the AP.
Through the PC connected to the AP, the user can easily perform the web
management after the following configuration.
The default IP address of the AP is 192.168.170.1 and this parameter can be set
as required. The following takes the default value as an example. The PC is set
by the following steps:
1) Connect the PC to the port of the AP.
2) Set the IP address of the PC.
3) Select Network > Network > Local Connection.
4) Right-click Local Connection and click Properties on the displayed
menu.
5) Select Internet Protocol Version 4 (TCP/IPv4), as shown in Figure
2-1.
