11 Description
(See Page 1 - illustration 3)
1. ON/OFF Volume knob
2. LCD display
3. Charger connection
4. Headset connection
5. TX LED ( on when transmitting)
6. Call button
7. Menu button
– Enter the menu settings
8. Microphone
9. Speaker
10. Down button
– Select previous value in the menu
11. Up button
– Select next value in the menu
12. PTT-button
13. Antenna
See folded cover page - illustration 3
28. Charger connection
29. Charger LED ( on when charging)
12 LCD display information
(See Page 1 - illustration 2)
14. CTCSS indication
15. DCS indication
16. CTCSS/DCS value
17. Frequency indication in MHz
18. MHz indication
19. Keypad lock icon
20. Call receive type indication
21. Battery level indication
22. Channel number
23. RX icon
– Displayed when receiving
24. TX icon
– Displayed when transmitting
25. VOX indication
26. Scanning indication
27. Dual channel mode (DCM) indication
MTD90
LICENCE FREE 2-WAY RADIOS
Page 7
