(CONT’D)
5. MIDI B Gate Source: PGM_A = <ON>, MIDI_B = <FLASHES>
• PGM_B = <OFF> – Gate goes high with Note-on
• PGM_B = <ON> – Gate goes high when Velocity > 50%
• PGM_B = <PULSE> – Gate goes high when Mod Wheel > 50% (default)
• PGM_B = <FLASH> – LFO ([TAP] PGM_ A) This is a square wave LFO with User-dened frequency.
6. MIDI Clock: PGM_A = <FLASHES>
• PGM_B = <OFF> (default)
• PGM_B = <ON> – ON. Tempo follows the rate of the incoming MIDI clock.
7. Calibrate: MIDI_A & MIDI_B = <ALTERNATE>, PGM_A =<ON>, PGM_B = <OFF>
• [PRESS] PGM_B in order to Calibrate (Note: it takes time). This procedure calibrates the internal
connection of the MIDI-CV converter to the Voltage Controlled Oscillator.
