M2 ASSEMBLY GUIDE
WHAT’S IN YOUR KIT
Item
DUE Case-bottom
DUE Case-top
v1.2 Control Board
v1.2 DUE Control Shield
Micro-USB connector- 10ft
AC/DC Power Adapter (3 meter lead cable) w/ Sticker
120/240 Volt Power Cable (to adapter)
X/Y Axis Motors (ETONM)
Motor Power Cables (JST XH 6Pin to XH 6Pin)
Motor Mounting Brackets
Z Axis Mount
Ring Carriage
Ring Carriage Bearings
Roller Chains (335cm / 11 feet)
Sled
Stud Mount
Suction Cover
PVC Elbow 2”
Z Axis Motor (ETONM)
Z-Axis Motor Power Cable (JST XH 6Pin to PH 6Pin)
Meticulous Z Assembly; pre-assembled
Lanyard 15mm full color die-sub
16GB USB Drive with Firmware/Software/Instructions
MM White Sticker
Info sheet on FB community
Paint marker
Spring
Router Bit Case
1/4” upcut bit
1/8” downcut bit
2in wide black rubber stripping
Quantity
1
1
1
1
1
1
1
2
2
2
3
2
4
2
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
