M2 ASSEMBLY GUIDE : WHAT’S IN YOUR KIT
Item
Bag A
Cotter Pins to Secure chain to ring
Chain Guide
Chain Alignment Spacer
Chain Spacer Nail
Chain Nail
Bag B
Cable Tie
M5 Quick Link
Arduino Screws
Bag C
Brick Mounting Bolts
split washer
Nylon nut
Butterfly nut
Brick straps
Bag D
Short Wood Screws
#6-9 x 2-1/2” Phillips Bugle Head
Bag E
X/Y Axis Motor Mounting Screw
X/Y Axis Motor Split Lock Mounting Washer
Set Screw for Motor Sprocket
Set Screw Allen Wrench (3mm)
Motor Sprocket for Chain
Bag F
Shoulder Bolt
Shoulder Bolt Nut
Shoulder Bolt Washer
Shoulder Bolt Allen (5mm)
Bag G
Ring To Brace Bolts
M3-0.5 Wing Nut
Ring Brace Screws
Ring To Brace Bolts Allen (2mm)
Quantity
2
2
2
2
2
12
2
4
4
4
2
2
2
34
8
8
8
2
1
2
4
4
8
1
12
12
24
1
