2
Fig. 1 Fig. 2 Fig. 3
Fig. 4 Fig. 5 Fig. 6
Fig. 7 Fig. 8
1
2
3
4
5
7
6
8
10
9
13
11
12
14
A DCF050
B 0.15/0.10 0.17/0.12
C
113 mm x 72 mm x 36 mm
127 mm x 74 mm x 71 mm 127 mm x 74 mm x 88 mm 147 mm x 74 mm x 71 mm 141 mm x 74 mm x 88 mm
D BL1415 BL1430 BL1440 BL1815 BL1815N BL1830 BL1840
E 14.4 V 18 V
F 3/7 8/17 10/22 4/9 4/10 10/20 13/27
G 0.57 kg 0.76 kg 0.60 kg 0.85 kg
