14 ENGLISH
ASSEMBLY
CAUTION: Always be sure that the tool is
before carrying out any work on the tool.
Installing or removing driver bit/socket bit
Fig.16
Use only driver bit/socket bit that has inserting portion shown
For tool with shallow driver bit hole
A=12mm
B=9mm
Use only these type of driver
bit. Follow the procedure
1. (Note) Bit-piece is not
necessary.
For tool with deep driver bit hole
A=17mm
B=14mm
To install these types of driver
bits, follow the procedure 1.
A=12mm
B=9mm
To install these types of driver
bits, follow the procedure 2.
(Note) Bit-piece is necessary
for installing the bit.
Procedure 1
For tool without one-touch type sleeve
Fig.17: 1. Driver bit 2. Sleeve
To install the driver bit, pull the sleeve in the direction of
the arrow and insert the driver bit into the sleeve as far
as it will go.
Then release the sleeve to secure the driver bit.
For tool with one-touch type sleeve
To install the driver bit, insert the driver bit into the
sleeve as far as it will go.
Procedure 2
In addition to Procedure 1, insert the bit-piece into the
sleeve with its pointed end facing in.
Fig.18: 1. Driver bit 2. Bit-piece 3. Sleeve
To remove the driver bit, pull the sleeve in the direction
of the arrow and pull the driver bit out.
NOTE: If the driver bit is not inserted deep enough
into the sleeve, the sleeve will not return to its original
position and the driver bit will not be secured. In this
case, try re-inserting the bit according to the instruc-
tions above.
NOTE:
the sleeve and insert it into the sleeve as far as it will
go.
NOTE: After inserting the driver bit, make sure that it
Installing hook
Optional accessory
The hook is useful to hang the tool. Install the hook to
the holes on the tool body.
Fig.19: 1. Hook 2. Hole
OPERATION
Screwdriving operation
CAUTION:
driver bit/socket bit securely over the screw head/
bolt head during fastening operation. Failure to
do so may cause mishandling of the tool resulting in
personal injury.
CAUTION: Make sure that the driver bit/
socket bit is placed straight over the screw head,
or the screw and driver bit/socket bit may be
damaged.
CAUTION: Keep hands away from the rotating
parts during operation. Failure to do so may cause
your hands to be caught in the moving parts, resulting
in personal injury.
Place the tip of the driver bit/socket bit straight over the
screw head/bolt head, apply pressure to the tool, and
then switch the tool on.
The tool automatically stops the motor when the output
torque reaches the target torque set in the application
software. Release the switch trigger after the tool
comes to a complete stop.
Fig.20
Limits of fastening capacity
NOTICE: Operating temperature range
Use the tool in the recommended ambient tempera-
ture range of 0 °C - 40 °C. Operation outside the
recommended temperature may reduce the tool
unstable output torque.
Use the tool within the limits of its fastening capacity.
If you use the tool beyond the limits, the output torque
may be reduced as a means of tool protection.
For model DFT060T
2.0 6.03.0 5.0
4.0
360°
300°
240°
180°
120°
60°
30°
1
3
2
N•m
1. Range of fastening capacity 2. Rotation angle
3. Torque
