Makita DLS714 Technical Information

P 2/ 47
TCT saw blade 190mm
Dust bag
Holder set
Hex wrench
Vertical vise
Triangular rule
Battery*
1
Battery cover*
2
Charger*
1
*1 Battery and Charger are not supplied with “Z” model.
*2 Supplied with the same quantity of extra Battery.
Note: The standard equipment may vary by country or model variation.
TCT saw blades
Horizontal vise
Set plate assembly
Holder assembly
18V Li-ion battery BL1815N; BL1820, BL1820B; BL1830; BL1840, BL1840B; BL1850, BL1850B
Fast charger DC18RC
Charger DC24SC
Charger DC18SD
Automotive charger DC18SE
Four port multi charger DC18SF
Two port multi fast charger DC18RD
S
tandard equipment
O
ptional accessories

Makita DLS714 Specifications

General

Blade Diameter	190 mm
Max Cutting Capacity at 90°	52 x 300 mm
Max Cutting Capacity at 45°	52 x 212 mm
Power Source	Corded Electric
Bore Diameter	20 mm
Voltage	240 V
Maximum cutting depth at 90°	52 mm
Maximum cutting depth at 45°	52 mm
Bevel Capacity	45° left and right
