SPECIFICATIONS
Model: DSP600 DSP601
Blade diameter 165 mm
Max. Cutting depth at 0° 56 mm
at 45° bevel 40 mm
at 48° bevel 38 mm
No load speed 2,500 - 6,300 min
-1
Overall length 346 mm
Rated voltage D.C. 36 V
Battery cartridge BL1815N, BL1820, BL1820B, BL1830, BL1830B, BL1840,
BL1840B, BL1850, BL1850B, BL1860B
Charger DC18RC, DC18RD, DC18SD, DC18SE, DC18SF
Net weight 4.4 - 5.1 kg
•
Due to our continuing program of research and development, the specications herein are subject to change without notice.
• Specications and battery cartridge may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combinations, according to EPTA-Procedure 01/2014, are shown in the table.
Intended use
The tool is specially intended for performing plunge cuts. The tool is
also intended for rip and cross cuts in wood. If the tool is equipped
with proper circular saw blade, the tool can be used for sawing
aluminum, plastic, mineral contained plastic, and similar materials.
Noise
The typical A-weighted noise level determined according to EN62841:
Model DSP600
Sound pressure level (L
pA
) : 92 dB(A)
Sound power level (L
WA
) : 103 dB (A)
Uncertainty (K) : 3 dB(A)
Model DSP601
Sound pressure level (L
pA
) : 92 dB(A)
Sound power level (L
WA
) : 103 dB (A)
Uncertainty (K) : 3 dB(A)
NOTE:
The declared noise emission value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE:
The declared noise emission value(s) may
also be used in a preliminary assessment of exposure.
WARNING: Wear ear protection.
WARNING:
The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the tool is
used especially what kind of workpiece is processed.
WARNING:
Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (tak-
ing account of all parts of the operating cycle such
as the times when the tool is switched off and when
it is running idle in addition to the trigger time).
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN62841:
Model DSP600
Work mode: cutting wood
Vibration emission (a
h,W
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
Work mode: cutting metal
Vibration emission (a
h,M
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
Model DSP601
Work mode: cutting wood
Vibration emission (a
h,W
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
Work mode: cutting metal
Vibration emission (a
h,M
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also
be used in a preliminary assessment of exposure.
WARNING: The vibration emission during
actual use of the power tool can differ from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
