Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heaviest
combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
• Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.
WARNING:
• Only use the battery cartridges and chargers listed above. Use of any other battery cartridges and chargers may
cause injury and/or fire.
Symbol
END013-5
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
....... Read instruction manual.
................... Do not expose to moisture.
............ Only for EU countries
Do not dispose of electric equipment or
battery pack together with household
waste material!
In observance of the European
Directives, on Waste Electric and
Electronic Equipment and Batteries
and Accumulators and Waste Batteries
and Accumulators and their
implementation in accordance with
national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be
collected separately and returned to an
environmentally compatible recycling
facility.
Intended use
ENE014-1
The tool is intended for trimming hedges.
1. Red indicator
2. Button
3. Battery cartridge
4. Star marking
5. Indicator lamps
6. Check button
7. Switch trigger A
8. Switch trigger B
9. Lock-off button
10. Indication lamp
11. Cutting height
12. 10 cm
13. Trimming direction
14. Hedge surface to be trimmed
15. Tilt the blades
16. String
17. Press
18. Chip receiver
19. Nut
20. Shear blade
21. Hooks
22. Fit the hooks into groove
23. Grooves
24. Press the levers on both sides
25. Unlock the hooks
26. Screws
27. Under cover
28. Sponge
29. Washer
30. Gear
31. Sleeves
32. Groove
33. Blade cover
34. Grease
35. Blade
Model DUH481 DUH483 DUH521 DUH523
Blade length 480 mm 520 mm
Strokes per minute
(min
-1
)
1,350
Rated voltage D.C.14.4 V D.C.18 V D.C.14.4 V D.C.18 V
Overall length
(Depending on the
battery)
869 - 881 mm 873 - 888 mm 919 - 931 mm 923 - 938 mm
Net weight 3.0 - 3.2 kg 3.0 - 3.3 kg 3.0 - 3.2 kg 3.0 - 3.4 kg
Battery cartridge
D.C.14.4 V Model BL1415N/BL1430/BL1430B/BL1440/BL1450/BL1460B
D.C.18 V Model
BL1815N/BL1820/BL1820B/BL1830/BL1830B/BL1840/BL1840B/
BL1850/BL1850B/BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF/DC18SH
