Page #11 background imageLoading...
Page #11 background image
11
12. TROUBLESHOOTING
WARNING: Before performing any maintenance
or cleaning work, always pull out the mains plug and wait
until the cutter has come to a standstill.
CAUTION: Faults which can not be rectified with
the aid of this table may be rectified by Makita authorized
service center only.
13. ENVIRONMENTALLY
FRIENDLY DISPOSAL
According to EU directive on electric and
electronic equipment and its implementation
into national law, all electric tools must be
separately collected and environmentally
friendly recycled. Alternative disposal: If the
owner of the power tool does not return the
tool to the manufacturer, he is responsible for proper
disposal at a designated collection point that prepares the
device for recycling according to national recycling laws
and regulations.
This does not include accessories and tools without
electric or electronic components.
14. EC DECLARATION OF
CONFORMITY
(For European countries only)
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):
Designation of Machine: Electric Lawn Mower
Model No. /Type: ELM3800
Specifications: See “4. Technical Data” are of series
production and
Conforms to the following European Directives:
2004/108/EC, 2006/42/EC,
2000/14/EC & 2005/88/EC, 2006/95/EC
And are manufactured in accordance with following
standards or standardized documents
EN 60335-1, EN 60335-2-77, EN 62233,
EN 55014-1, EN 55014-2, EN 61000-3-2,
EN 61000-3-3
The technical documentation is kept by:
Makita International Europe Ltd.
Technical department,
Michigan Drive, Tongwell,
Milton Keynes, Bucks MK15 8JD, England
The conformity assessment procedure required by
Directive 2000/14/EC was in Accordance with Annex VI.
Notified Body:
TÜV SÜD Industrie Service GmbH
Westendstraße 199, 80686 München, Germany
Identification Number: 0036
Model: ELM3800
Measured Sound Power level: 93.4 dB(A)
Guaranteed Sound Power level: 96 dB(A)
13. 12. 2013
Tomoyasu Kato
Director
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, 446-8502, JAPAN
Fault Remedial action
Motor does not
run
Check mains connection cable.
Start on short grass or on an area
which has already been mown.
Clean discharge channel/housing - the
mowing blade must rotate freely.
Correct the cutting height.
Check motor carbon brush, if discover
finished, please replace HT118.
Motor power
drops
Correct the cutting height.
Clean discharge channel/housing.
Have mowing blade resharpened/
replaced authorized service centre.
Grass catcher
is not filled
Correct the cutting height.
Allow the lawn to dry.
Have mowing blade resharpened/
replaced authorized service centre.
Clean the grille on the grass catcher.
Clean the discharge channel/housing.
Wheel drive
does not
function
Adjust the flexible cable.
Check the V-belt/gears authorized
service centre.
Check the drive wheels for damage.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Makita ELM3800 and is the answer not in the manual?

Makita ELM3800 Specifications

General IconGeneral
TypePush lawn mower
Cutting width380 mm
Grass catcherYes
Cutting system-
Number of wheels4 wheel(s)
Recommended lawn area600 m²
Maximum cutting height75 mm
Minimum cutting height25 mm
Grass collecting volume40 L
Power sourceAC
Weight and Dimensions IconWeight and Dimensions
Weight13000 g
