11 ENGLISH
4. To have the better sound quality, we recommend
setting the volume to more than two-thirds level on your
audio device and then adjust the volume on the radio
as required.
Note:
Audio cord is not included as standard accessories. AUX
can’t be activated as alarm source.
MAINTENANCE
CAUTION:
●
Never use gasoline, benzine, thinner, alcohol or the
like. Discoloration, deformation or cracks may result.
●
Do not wash the radio with water.
SPECIFICATIONS
Power requirements
AC power adapter
DC 12V 0.7A, center pin
positive
Battery
UM-3 (AA size) x 2 for back up
Slide battery: 10.8V - 36V
Frequency coverage
FM 87.50-108 MHz
(0.1MHz/step)
AM (MW) 520-1,710 kHz
(10kHz/step)
Circuit feature
Loudspeaker 3.5inches 8ohm x 2
Output power
10.8V-12V max: 1.2W x 2
14.4V: 2.2W x 2
18V: 3.5W x 2
36V: 5W x 2
Input terminal 3.5mm dia. (AUX IN)
Antenna system
FM: Built-in antenna
AM: bar antenna
Dimensions (L x W x H) 278 x 170 x 298mm
Weight 4.3kg (without battery)
