8
Installing or removing the bit
Clean the bit shank and apply bit grease before installing the
bit.
Insert the bit into the tool. Turn the bit and push it in until it
engages.
If the bit cannot be pushed in, remove the bit. Pull the tool
holder cover down a couple of times. Then insert the bit
again. Turn the bit and push it in until it engages.
After installing, always make sure that the bit is securely held
in place by trying to pull it out.
To remove the bit, pull the tool holder cover down all the way
and pull the bit out.
Bit angle
The bit can be secured at 12 different angles. To change the
bit angle, slide the change ring forward, then turn the change
ring to change the bit angle. At the desired angle, slide the
change ring back to the original position. The bit will be
secured in place.
NOTE:
• The change ring cannot turn when the bit is not installed
on the tool.
1. Bit grease
2. Bit shank
1
2
002916
1. Bit
2. Tool holder cover
1
2
002922
002923
1. Change ring
1
002939
