10
Fit the wool bonnet completely over the rubber pad and pull
the string tight. Tie a bow knot and tuck the knot and any
loose strings between the wool bonnet and the rubber pad.
To remove the wool bonnet, follow the installation procedure
in reverse.
Installing or removing abrasive disc
(optional accessory)
NOTE:
• Use sander accessories specified in this manual. These
must be purchased separately.
Mount the rubber pad onto the spindle. Fit the abrasive disc
on the rubber pad and screw the lock nut onto the spindle.
To tighten the lock nut, hold the spindle with the wrench so
that it cannot revolve, then use the lock nut wrench and
securely tighten clockwise.
To remove the disc, follow the installation procedure in
reverse.
OPERATION
Polishing operation by sponge pad
CAUTION:
• Always wear safety glasses or a face shield during
operation.
In general, keep the sponge pad at an angle of about 15
degrees to the workpiece surface.
003470
1. Lock nut
2. Abrasive disc
3. Rubber pad
4. Spindle
1
2
3
4
003414
1. Lock nut wrench
2. Wrench
1
2
003418
003479
