Makita UH6350 Parts List

PARTS BREAKDOWN
EM4251
1 of 16
06/10/2010
Tech Bulletins Fig. No. Part No. Description Q'ty Uni
t
1 970-801-820 ROTOR ASS'Y, UH5530 1
2 970-801-220 STATOR ASS'Y. UH5530 1
3 960-101-074 BALL BEARING, UH5530 1
4 960-101-104 BALL BEARING, UH5530 1
5 957-801-410 CARBON BRUSH CPL., UH5530 2
78002-WW-1 6 970-001-210 SWITCH, UH5530 2
6 970-001-210 SWITCH, UH5530 2
10 970-201-220 SCREW WIRE CONNECTOR, UH5530 1
11 970-311-250 CONNECTING CABLE, UH5530 1
12 970-311-280 CONNECTING CABLE, UH5530 1
13 970-311-270 CONNECTING CABLE, UH5530 1
14 204-152-010 BREAK PROTECTION, UH5530 1
15 222-111-030 GASKET UH5550 1
16 221-213-111 HAND GUARD, UH5530 1
17 980-114-292 LABEL, UH5550 1
18 913-540-205 SCREW 4.0X20, UH5530 2
19 221-310-111 TUBULAR HANDLE,UH5550 1
20 221-145-110 PRESSURE SPRING, UH5530 1
21 917-005-250 SCREW, UH5530 2
22 221-144-110 FRONT GRIP SWITCH, UH5530 1
23 222-110-610 CASE CPL.,BLUE UH5550 1
24 913-540-205 SCREW 4.0X20, UH5530 9
25 222-111-050 HEXAGONAL NUT M5,UH5550 6
26 920-205-000 HEX NUT M5, DCS340 2
27 920-205-000 HEX NUT M5, DCS340 1
28 222-111-040 DUST PROTECTION,UH5550 1
29 980-114-296 LABEL, UH5550 1
30 221-144-120 REAR GRIP SWITCH, UH5530 1
31 221-145-120 PRESSURE SPRING, UH5530 1
32 222-144-130 SWITCH FORK,UH5550 1
34 203-152-050 TRACTION RELIEF, UH5530 1
35 970-801-650 TUBE 1
36 915-635-164 SELF CUTTING SCREW 3.5X16, UH5530 2
37 222-220-020 GEAR CPL., UH6350 1
37 221-220-020 GEAR COMPLETE, UH5530 1
37 221-220-021 GEAR ASSEMBLY 1
37 221-220-022 GEAR ASSEMBLY 1
37 222-220-020 GEAR CPL., UH6350 1
38 222-211-010 GEAR PLATE W/AXLE,UH5550 1
39 253215-0 F. WASHER 8, PV7001C 1
39 221-229-180 WASHER, UC3500, UC4000 1
40 253215-0 F. WASHER 8, PV7001C 1
40 221-229-180 WASHER, UC3500, UC4000 1
41 222-233-610 PLATE UH5550 1
42 222-230-660 SHEAR BLADE 63CM, UH6350 1
43 222-233-460 BAR 63CM, UH6350 1
44 222-233-290 SHEAR PLATE A, UH6350 1
45 222-233-390 SHEAR PLATE B, UH6350 1
46 222-233-540 GUIDE PLATE, UH6350 1
Products with multiple versions are listed in subsiding order with the newest version on top not indented.
Corresponding bulletins are attached. Select bulletin name or attachment to view.
PARTS BREAKDOWN
UH6350
rev 0_08/02/2010
Page 2 of 3
PB_06-2010_rev 0

Makita UH6350 Specifications

General

Brand	Makita
Model	UH6350
Category	Trimmer
Language	English
