Malco Products, Inc., 361 Fairview Avenue, Barberton, Ohio 44203
Phone 800-253-2526 or 330-753-0361; Fax 330-753-2025 9-13-01 REV1 Page 12
MALCO XTRAX™
MODEL 1200 XTRACTOR
PARTS LIST
Part Number Description Qty
B-10 6-32 X 1/2 PHXSS 8
B-14 NUT 6-32 HEX SS 8
B-17.2 8-32 X 1/2 PHXSS 4
B-17.6 8-32 X 3/4PHX ZINC 4
B-18.02 NUT 8-32 NYLOK, ZINC 4
B-21 10-32 X 5/16 PHXSS 6
B-23 10-32 X 1/2 PHXSS 1
B-23.7 10-32 X 5/8 PHXSS 8
B-24 10-32 X 3/4 PHXSS 2
B-26.7 10-32 X 1 1/2 PHXZINC 2
B-28.01 NUT 10-32 HEX ZINC 5
B-28.02 NUT, 10-32 SS NYLOCK 6
B-31.5 1/4-20 X 1/2 HEX CP 4
B-32 1/4-20 X 3/4 HEX HD CP 12
B-32.6 1/4-20 X 3/4 PHXFLTHD SS 6
B-33.05 1/4-20 X 1 HEX HD SS 2
B-33.38 1/4-20 X 3 HEX HD CP 1
B-33.4 1/4-20 X 3 3/4 HEX CP 5
B-36.01 NUT 1/4-20 NYLOK ZINK 13
B-36.02 NUT 1/4-20 NYLOK SS 8
B-38.5 WASHER, 1/4 FLAT CP 13
B-38.6 WASHER, 1/4 FLAT SS 4
B-39.5 WASHER, 1/4 INT. STAR 1
B-40.91 3/8-16 X 1 1/2 HEX ZINC 2
B-40.95 3/8-16 X 3 1/2 HEX ZINC 1
B-40.96 3/8-16 X 4 HEX ZINC 1
B-41.5 WASHER, 3/8 FLAT ZINC 3
B-42 WASHER 9/16 x 1 1/4 FLAT 6
B-43 NUT 1/2-20 HEX JAM BRASS 2
B-48 NUT, 1/4" BULK HD 3/4-16 2
C-01.25 BUSHING,HOLDER EMPTY-OUT 1
C-02.3 CASTER 3 1/2" 2
C-03.02 CLAMP, HOSE 1/4" #4 1
C-03.13 CLAMP, HOSE 1 3/4 #20 2
C-03.2 CLAMP, HOSE 2" #24 1
C-03.3 CLAMP, HOSE 2 1/4 #32 6
Part Number Description Qty
C-04.1 COTTER, HAIRPIN 7/16-9/16 2
C-05.05 FILTER, 1/4NPT 50MESH 1
C-06 GASKET, BLOWER/ARLON 1/4" 2
C-07.2 GASKET, DOME LID 1
C-07.3 GASKET,VAC SEAL EDGE BASE 1
C-11.9 LATCH, SOFT DRAW BLACK 2
C-13.5 PLUG, HOLE NYLON .562 3
C-22.5 TAPE, FOAM 2.5
C-23.8 WHEEL 10" - 1/2"BORE 2
C-26 FLOAT,VAC SHUT OFF ROTO 1
C-35.5 HOSE BARB,1 1/2XMPT W/FLA 1
C-56 O-RING, 1.75 X .187 2
C-59 PUSHNUT FASTNER, 1/2 CAP 2
C-94 VELCRO STRAP HOLD, EDGE 1
D-01.8 BULK HEAD, 1/4" 1
D-15.2 45 ST ELBOW 1/4 NPT 1
D-20.01 ELBOW 90 1/4NPT X -4 SAE 1
D-20.03 ELBOW 90 3/8NPT X -6 SAE 2
D-33 HOSE BARB 1/4MPTx1/4 HOSE 3
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
E-14 CUFF, 1 1/2SLIP X 1 1/4HOSE 1
E-14.65 CUFF, 1 1/2 SLIP 1 1/2 HO 2
F-09 Q/C 1/4" PLUG BR SHUT OFF 2
F-11 Q/C 1/4" SOC BR SHUT OFF 2
J-30 LID, DOME EDGE 1
J-40BLK BASE, EDGE ROTOMOLD BLACK 1
J-41SOL/GRANITE SOLUTION TANK,EDGE2 GRANITE AS MOLD 1
J-41VAC/GRANITE TANK,VAC ROTO GRANITE MALCO SS TNK 1
J-42GRANITE HANDLE EDGE ROTOMOLD GRANITE 1
J-43.5BLK NECK, VAC FLTR EDGE 2 ROTO 1
J-45.5BLK PMP MNT,CE SILNCE BLCK ED 1
J-48MALCO LID, SOLUTION EDGE 2 GRANITE MALCO 1
K-09.1 POWER CORD,12/3 X 25' YELLOW 1
K-12.15 HEATER,1750W 110V TUBULAR 9.8X6.48 1
K-13.3 LIGHT, RED ROUND 1
K-16.96 BUSHING,RELIEF 1/2 NPT 1
