9MALLORY TECHNICAL SUPPORT (775) 882-6600 tech@mrgasket.com
BLACK (LARGE 14 GA)
TO BATTERY NEG ()
RED (LARGE 14 GA)
TO BATTERY POS (+)
®
PART No. 6852
MICROPROCESSOR CONTROLLED CD IGNITION SYSTEM
R
MAGNETIC PICKUP
NOT USED
WHITE
RED (SMALL 18 GA)
RED
JUMPER
WHITE JUMPER
NOT USED (TAPE END)
ORANGEBLACK
(SMALL
18 GA)
FROM DISTRIBUTOR
PINK
BROWN
HEAVY PINK, ORANGE, OR RED WIRE
GREEN
PURPLE
PART OF MALLORY
HEI KIT P/N 29008
(NOT INCLUDED)
Installing the HYFIRE
®
VIA with
an External 4-Terminal Coil
(Single Connector)
®
PART No. 6852
MICROPROCESSOR CONTROLLED CD IGNITION SYSTEMMICROPROCESSOR CONTROLLED CD IGNITION SYSTEM
R
BLACK (SMALL 18GA)
ORANGE
YELLOW
GREEN
COIL
+

TO TACHOMETER
BLACK (LARGE 14GA)
RED (LARGE 14GA)
PURPLE
TO BATTERY NEG ()
TO BATTERY POS (+)
MAGNETIC PICK-UP
(NOT USED)
GREEN
RED
WHITE
(SMALL 18 GA)
RED (SMALL 18 GA)
Installing the HYFIRE
®
VIA with a Ford
Duraspark using the White Wire Trigger
