CONTINUOUS DRAINING
CAUTIONS
• Make sure that the drain hose is installed properly without warping upward.
If there is a place suitable for draining nearby, you can carry out continuous draining
operation. The continuous operation enables dehumidifying operation for hours without
having to empty the water tank. Before operating continuous draining, make sure to turn
off the dehumidifier and disconnect the power plug.
Drain pipe is not supplied.
Inner dimension: Ø15 mm.
Outer dimension: Ø20 mm or less.
Installation of drain pipe
• Remove the plastic piece on top of the filler
block.
• Remove the filler block in the draining port using
pliers.
• Fit the drain pipe into the opening and secure it.
Fitting operation of the drain pipe
Make sure that:
• The hose is not bent
• The end of the pipe is not in water
• The pipe is not warped upwards
Note: Always test the dehumidifier so that the drainage is working properly before leav-
ing it.
