Malmbergs UT1300B - Digital Multimeter; Safety Information

MJ-HE/JZ-140423
Digital Multimeter
Model: UT1300B 42 031 01
INSTRUCTION MANUAL
CONTENTS
• 1 Multimeter with test leads.
• 1 Battery 9V 6LF22 / PP3.
• 1 Instruction Manual.
SAFETY INFORMATION
• Do not use the meter if it, or the test leads, are damaged.
• Test the functions before use, by connecting the meter to a known voltage source.
• Never touch the probes during measurement/test.
• Only use the instrument within specified ranges and never above 600V when measuring voltage.
• If the instrument indicates overload, ”1” is shown in the display. Immediately stop the measuring.
• If the battery symbol shows in the display, the battery must be changed immediately to ensure that the read-
ings are correct.
• To avoid electric shock, be very cautious while measuring.
• Do not use the instrument in high humidity environment.
GENERAL SPECIFICATIONS
Display: 4 Digit LCD with a max. reading of 1999.
Range control: Manual.
Polarity indication: Yes.
Overload protection: Display shows ”1”.
Auto OFF: 25 minutes.
Safety standards: CE, EN 50081-1, EN 55022, EN 50082-1, IEC1000-4-2/-3.
Battery indication: When battery is low, ”
” is displayed.
Battery: 1x9V 6LF22 / PP3 battery.
Dims. LxWxD: 125x75x20 mm.
Weight: 145 g incl. batteries.
OVERVIEW
Function switch
Position Range Measuring method Position Range Measuring Method
V~ 500V AC Voltage mA 200mA AC Current
V~ 200V AC Voltage
mA
9V Battery test
hFE 0 – 1000 Transistor test
mA
1.5V Battery test
Ω 2000kΩ Resistance measurement V 2000mV DC Voltage
Ω 200kΩ Resistance measurement V 20V DC Voltage
Ω 20kΩ Resistance measurement V 200V DC Voltage
Ω 2000Ω Resistance measurement V 500V DC Voltage
Diode & Continuity test
