Slide lock for G-lock type
@
holder
Coupling pin for
film wind-stop releasing
When the shutter is released, the film
wind-stop is automatically disengaged
by this pin, allowing subsequent film
advances.
Light baffle
Do NOT touch this light baffle with your
fingers.
Revolving adapter
Turning this adapter up to
90D
permits
change-over between the horizontal
and
vertical
picture format.
R-lock lever
Use this lever to attach and detach the
revolving
adapter
This socket is applicable to a U
1/4-inch
tripod screw. By removing the inner
socket, a tripod with a 3/8-inch tripod
~~~~~~~~~~ing
base
Use this lock to attach and detach
a
film holder. When the dark slide is not
inserted in the attached roll film holder,
a safety device prevents the holder
from being detached.
Coupling pin for
multi-
exposure prevention
Release lever for slide lock
When detaching a film holder other
than the roll film holder, or when the
slide lock is locked,
move
the
slide
lock to the left while pressing
this
release
lever.
Tripod socket
8
