CLEANING & MAINTENANCE
Understanding the Air Purifier
(Front View)
When the purifier no longer produces enough ozone to be effective, the ozone plate
should be cleaned. A good rule of thumb is every month. Some environments cause
ozone output to be reduced in a shorter time but other environments may take longer.
To clean a plate, first turn the unit OFF and UNPLUG it from the wall outlet. Remove
the 4”x4” plates from back of unit. Pull plates firmly in the center to remove them from
the slot. With plate firmly supported in the hand; apply a solution of warm water and
ammonia (50/50 solution is suggested) or a strong grease cutting detergent. Scrub with a
stiff brush if necessary. Be careful not to drop the plate or scrub off the silicone. Clean
both the metal screen and the ceramic tile. Rinse plate in hot water and DRY
COMPLETELY before installing. If available you may use a hair dryer to dry the plate.
Reinstall plate, making sure it is secured and flush with the back of the unit. Plug unit
into a grounded electrical outlet, turn unit on and start enjoying clean fresh air.
To clean needlepoint ionizer, first turn it OFF and UNPLUG it from the wall outlet.
Remove the fan grill cover. The needle point ionizer will be easy to find in front of the
fan by looking for two pieces of wire. Take a q-tip or cotton swab dipped in alcohol and
clean any dust that may have accumulated on the needlepoints. This process may be
done when plates are being cleaned. While you have the front grill cover off the unit you
may also clean the fan and grill itself. To clean the fan, simply wipe the blades with a
damp cloth or vacuum. The grill cover may also be cleaned with warm soapy water.
Make sure that the fan grill cover is completely dry before installing.
Fan Grill
Manual Button
LCD
Display
panel
Remote
Controller
PART FUNCTION
LCD display panel Displays working status, time; with blue backlight
optional.
Remote Controller Controls the working status of the air purifier.
Manual Button Controls the air purifier by hand.
Fan Grill Removable fan grill. Wash with warm soapy water,
dry completely before replacing.
(Unplug unit before removing)
The control for the negative ion generator is separate from the O
3
control.
Negative ions can be created around the clock to reduce dust and particles.
O
3 -
also known as activated oxygen is normally kept at modest levels in
occupied spaces. To remove heavy odors, the units may be adjusted to a higher
level for a period of time. Some use a timer to completely deodorize the home
or office while away. Unused O
3
reverts back to O
2
in approximately one hour.
If you suspect a problem with your unit check the following:
• Make sure plate is clean (see above).
• Unit is plugged in properly and turned on.
• Check the fuse to make sure it is installed properly and not burned out. To replace
fuse, push in and turn fuse holder to the left, remove old fuse, replace with spare.
Use 1 amp fuse, 1.25 inches long.
• Confirm that the wall outlet is active.
• Check plate alignment making sure the ceramic plate is flush with back of unit.
• It is important that the Air purifier be properly grounded to avoid potential shock.
TROUBLESHOOTING
Caution: Turn Power Switch OFF when opening the back panel of the unit
to replace parts.
-3- -8-
