AGGREGATE – FÜLLMENGEN
HINTERACHSEN
Füllmenge:
Achstyp Gesamt Mitteltrieb*
)
Zentralvorgelege*
)
Planetentrieb
H 7 – 0880 M/G (normalbreit).................... 12,0 9,0
——
2 x 1,5
H 7 – 0880 M/G (überbreit)........................ 13,7 10,7
——
2 x 1,5
H 7 – 1080/1180/1380 (M)
8 – Radbolzen ......................................
10 – Radbolzen ......................................
16,0
16,0 (14,0)
9,0
9,0
——
——
2 x 3,5
2 x 3,5 (2 x 2,5)
H 7 – 13120 – M (normalbreit)................... 15, 8 12,8
——
2 x 1,5
H 7 – 13120 – M (überbreit) ...................... 17,0 14,0
——
2 x 1,5
H 9 – 0670 - 00/01..................................... 10,0 8,5
——
2 x 0,75
H 9 – 0970 - 00/01..................................... 11,5 7,5
——
2 x 2,0
H 9 – 13120/16120.................................... 20,0 13,0
——
2 x 3,5
H 9 – 1180/1380........................................ 16,0 9,0
——
2 x 3,5
H 9 – 13120 (Trilexradstern) / 2,9 m.......... 18,0 / 19,0 13,0 / 14,0
——
2 x 2,5
H 9 – 1380 (Trilexradstern)........................ 14,0 9,0
——
2 x 2,5
HD 7 – 0880 M/G (normalbreit) ................. 14,0 9,0
2,0
2 x 1,5
HD 7 – 0880 M/G (überbreit)..................... 15,7 10,7
2,0
2 x 1,5
HD 7 – 13120 – M (normalbreit)................ 21,5 16,5
2,0
2 x 1,5
HD 7 – 13120 – M (überbreit).................... 22,8 17,8
2,0
2 x 1,5
HD 9 – 1180/1380 ..................................... 20,0 11,0
2,0
2 x 3,5
HD 9 – 13120/16120 ................................. 23,0 14,0
2,0
2 x 3,5
HD 9 –13120 2,9 m ................................... 24,0 15,0
2,0
2 x 3,5
HD 9 – 1380 (Trilexradstern)..................... 18,0 11,0
2,0
2 x 2,5
HO 7 – 11120 ............................................ 20,0 13,0
——
2 x 3,5
*
)
Mitteltrieb und Zentralvorgelege haben einen gemeinsamen Ölhaushalt
