Design and Function
MAN marine diesel engines D2868 LE.. / D2862 LE4..
32
Carefully read through the Operating Instructions before starting any work!
This particularly applies to the General Safety Instructions section
and the safety instructions in the various chapters.
4.3.2 Rear right view
The picture shows an D2862 LE4.. engine with 1-stage turbocharching (example).
1
Exhaust pipe, liquid cooled
2
Fuel pre-filter with hand priming pump
3
Flywheel
4
Sea water pump
