Maintenance and Care
78
Carefully read these Operating Instructions before starting any work!
This is especially valid for the chapter on General Safety Instructions
and the safety instructions in each of the chapters.
Check Engine Oil Level
NOTE
Ensure that all of the engine's oil supply has collected in the oil pan
For this reason:
S Perform the oil level check with the engine in a horizontal position, having waited around 5 minutes
after stopping the machine.
Stop the engine.
Perform the oil level check after around 5 minutes:
S Pull the oil dipstick
1
out.
S Wipe the oil dipstick
1
with a clean, lint-free
cloth.
S Reinsert the oil dipstick
1
as far as the stop.
S Pull the oil dipstick
1
back out.
The oil level should be between both of the marks
on the dipstick and should never drop below the
lower mark.
S Top up the oil as necessary.
Do not overfill.
MIN
MAX
