Ref. # Part # Description Qty.
1 14342 Asm, Crank - Con Rod - 150cc 1
2 14324 Nut, M12 x 1.25 Hex Flange 1
3 14510 Nut, M22 x 1.00 Locking - 150CC 1
4 14511 Washer, M22 x 31 x 2.5 Flat 1
5 14344 Gear, Kick Drive 1
6 14289 Washer, M12 Flat 1
7 14324 Nut, M12 x 1.25 Hex Flange 1
8 14512 Key, Woodruff M4 x 14 1
9 14345 Clip, Piston Retaining - 150cc 2
10 14346 Pin, Piston Wrist - 150cc 1
11 14347 Piston - 150cc 1
12 14348 Kit, Piston Ring - 150cc 1
Section 7 - Piston, Crank and Connecting Rod
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
