Ref. # Part # Description Qty.
1 14326 Cover, Outer Crankcase RH - 150cc 1
2 14327 Gasket, Outer Crankcase - 150cc 1
3 14328 Cap, Oil Drain - 150cc 1
4 14329 Screen, Oil Filter - 150cc 1
5 14330 Spring, Oil Filter Screen - 150cc 1
6 14331 Dipstick, Oil Fill - 150cc 1
7 14332 Clamp, AC Generator - 150cc 1
8 14333 Seal, M19.8 x 30 x 5 Oil 1
9 14334 O-Ring, M30.8 x 3 1
10 14335 O-Ring, M18 x 3 1
11 50016 Pin, M8 x 14 Dowel 2
12 14336 Bolt, M6 x 1.00 x 28 FHCS 1
13 14337 Bolt, M6 x 1.00 x 95 FHCS 4
14 14338 Bolt, M6 x 1.00 x 100 FHCS 1
15 14339 Bolt, M6 x 1.00 x 110 FHCS 2
16 14340 Bolt, M6 x 1.00 x 35 FHCS 1
17 14341 Bolt, M6 x 1.00 x 20 FHCS 2
18 14296 Bolt, M5 x 0.75 x 12 FHCS 2
Section 6 - Outer Crankcase Assembly
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
