Ref. # Part # Description Qty.
1 14323 Cover, CVT - 150cc 1
2 14507 Bracket, Exhaust - 150cc 1
3 14324 Nut, M12 x 1.25 Locking Flange 1
4 14508 Bearing, 6200 10 x 30 x 9 2
5 14325 Gasket, CVT Cover - 150cc 1
6 14235 Bolt, M6 x 1.00 x 40 FHCS 8
7 14322 Snorkel, CVT - 150cc 1
8 14322 Snorkel, CVT - 150cc 1
9 14509 Clamp, Snorkel - 150cc 2
Section 5 - CVT Cover
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
