Ref. # Part # Description Qty.
1 14540 Cover, Fan Comp - 150cc 1
2 14541 Cover, Dust - 150cc 1
3 14542 Duct, Carburetor Cooling - 150cc 1
4 14543 Shroud, Lower - 150cc 1
5 14544 Seal, Lower Shroud - 150cc 1
6 14545 Shroud, Upper - 150cc 1
7 14546 Clip, Cord - 150cc 1
8 14547 Seal, Upper Shroud - 150cc 1
9 50065 Screw, 6
10 50069 Bolt, M6 x 25 FHCS 3
11 14539 Screw, 3.5 x 13 STFH 3
Section 15 - Fan Cover and Shroud Assembly
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
