Ref. # Part # Description Qty.
1 14561 KIT, CARB GASKET - 150CC 1
2 14562 KIT, CARB VACUUM - 150CC 1
3 14563 KIT, CARB CHOKE - 150CC 1
4 14564 KIT, CARB REBUILD - 150CC 1
5 14565 SCREW, M5 X 12 PH 3
6 14566 SCREW, M4 X 14 PH 2
7 14567 SCREW, M4 X 10 PH 2
Section 16 - Carburetor
10-31-07
ILLUSTRATED PARTS MANUAL - 6150
PART NUMBER 14570R2
