FEET
The tripod is supplied with twin metal spikes “K” for outdoor use. To use the metal spike, remove the foot “L” by pulling down the rubber retainer “M”.
MOUNTING A CAMERA HEAD
The tripod is designed for 100mm or 75mm ball heads. To mount 75mm ball heads, attach the adapter “N“ (provided) to the tripod with the three screws “M” .
NOTE
For increased support, pull lever "V" (fig. 12) towards the center of the tripod.
5
K
M
M
N
R
V
L
2
1
10
11
12
10 11 12
