Mangar Leglifter - Fitting Instructions (Profiling Beds)

4
Leglier
Fing instrucons (Proling Beds)
The exible construcon of the deated Leglier
makes it ideal for use with most types of proling bed.
However, please carefully follow these guidelines to
avoid any conict with moving secons of the bed.
• Remove the maress from the bed.
• Raise and lower the backrest and legrest secons
of the bed to idenfy strap posions which best
avoid chang/fouling of the straps.
• On the opposite side of the bed to where the
Leglier is to be ed, secure the loop end
of each strap to the inner frame as indicated
(A g.4). NOTE: Wrap the strap around the
frame several mes so as to shorten the strap
length, allowing the adjuster buckle to lie near
the centre line of the bed.
WARNING: When ng to a bed with a Low/High
funcon, ensure that the straps are aached to the
frame which moves up and down.
• Hook the two straps onto the ap of the Leglier as indicated in (B g.4) and pull on the strap at the
adjuster buckle to draw the ‘Vee’ of the deated Leglier inwards over the bed frame and under the
maress by about 1 to 2 ngers width (C g.5).
• Raise and lower the backrest and legrest secons of the bed, checking to ensure that the straps do not
interfere with the bed’s funcons.
• Ret the maress.
• Connect the Leglier to the Airo 12 compressor and with the backrest and legrest secons of the bed
in the horizontal posion, test that the Leglier inates to fully vercal against the maress. Tighten the
straps further if necessary. Upon nal adjustment, the edge of the ap seles to sit on the frame (under
the maress) by about 1 to 2 ngers width.
NOTE: Normally, the Leglier should be operated with all bed secons in the horizontal posion. If necessary,
the backrest can be raised up to 45° to assist upper body stability while the legs are raised.
WARNINGS:
• Do not operate the Leglier when the bed’s legrest is raised.
• Do not raise the bed’s legrest when the Leglier is inated.
• Always deate the Leglier aer the legs have been safely posioned on the bed.
NOTE: Where ed, any integral cotside on the transfer side of the bed must be removed to permit eecve
ng and operaon of the leglier.
A
B
C
NOTE: If the bed secons are of
metal grid construcon, ensure the
strap hook has its open side facing
upwards, to avoid fouling the grid.
4
5
