Manitou 100 SEC 2 User Manual

3-25
H4 - Lifting the machine with a forklift truck
HANDLING
- Ensure that the extension, the controls and the supports for the lifting platform’s
components are secured. Remove any elements not fastened to the machine.
- The lifting platform must be in transport position throughout all the loading and
transport operations.
- Use the slots for the forks on both sides of the ladder 1 (Fig. H4).
- Place the lift truck’s forks in position over the fork slots.
- Move the machine forwards up to the end of the forks.
- Raise the machine 15 cm and then tilt the forks slightly backwards so that the machine
remains stable.
- Ensure that the machine remains level when the forks are lowered.
H4
1
1
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
