2-10

ELECTRICAL CIRCUIT UNIT 100 SC-2 120 SC-2 140 SC TOL ±

Battery

C5 capacity Ah 75 75 75 -

C20 Capacity Ah - - - -

Nominal voltage V 12 12 12 -

Alternator

Type - - - -

intensity A 40 40 40 -

Voltage V 14 14 14 -

DIMENSIONS UNIT 100 SC-2 120 SC-2 140 SC TOL ±

Transport position

Width mm 1750 1750 1750 1%

Length mm 3760 3760 3760 1%

Height, stowed, rails uppered mm 2590 2590 2740 1%

Height, stowed, rails lowered mm 1920 1920 2080 1%

Heght maximum mm 1470 1470 1650 1%

Wheelbase mm 2290 2290 2290 1%

Work position

Work height mm 9800 11900 14000 1%

Floor height mm 8000 10000 12300 1%

Chassis clearance 1 mm 240 240 240 2%

INT drive gyration radius mm 2110 2110 2110 3%

EXT drive gyration radius mm 4600 4600 4600 3%

Basket

External dimensions mm 2790x1600 1%

Length extension mm 1530 1%

CAPACITY 100 SC-2 120 SC-2 140 SC TOL ±

Hydraulic oil reservoir l 62.5 62.5 62.5 2

Diesel tank l3838382

Engine oil sump l---2

Coolant circuit l---2

EQUIPEMENT 100 SC-2 120 SC-2 140 SC TOL ±

Emergency pump

Type Manuelle -

Flashing light Option -

Hour counter Série -

230V layout Série -

Stabiliser Série -

647367 (01/03/2017)

100/120 SC-2 / 140 SC
