2-37
RELEASING THE BRAKES
The platform may only be towed a short distance, and necessarily by a machine
with significant braking power to hold it, and with a connecting bar between
the two machines.
- To set the platform in Freewheel mode, it must not be subject to any translation stresses
caused by a slope. The wheels must be able to turn freely.
- Release the wheel brakes by turning over the two rear torque hub disconnect caps. Turn needle
valve on traction manifold counter-clockwise until it stops.
- Be sure the winch line is properly secured to the drive chassis tie points and the path is clear
of all obstructions.
- Reverse the procedures described to re-engage the brakes.
Note: The needle valve should always remain closed during normal operation.
Press the brake release pump button 2 (Fig. F).
- It is inadvisable to tow the 100 SC-2, 120 SC-2 and 140 SC models.
- If the platform must be towed, do not exceed 3.2 km/h.
Never try to push or pull the platform to start it. This type of manoeuvre would cause serious damage to the transmission.
C
1
B
Désengagée
Engagée
647367 (01/03/2017)
100/120 SC-2 / 140 SC
