2 - 72
10 - EXTERIOR DRAIN-BACK
Enables connection of an attachment for which drain-back is required.
11 - HYDRAULIC ATTACHMENT LOCKING
Enables attachment locking to be controlled on the carriage and the use of a hydraulic
attachment on the same hydraulic circuit (See chapter : PICKING UP THE
ATTACHMENTS in paragraph : 4 - ADAPTABLE ATTACHMENTS IN OPTION ON THE
RANGE).
12 - JIB HEAD ELECTROVALVE
Enables use of two hydraulic functions on the attachment circuit.
To make connection of the rapid connectors easier, decompress the hydraulic circuit
by pressing button 1 on the electrovalve.
FUNCTIONING
MLT 629/730 Série A
MT 732/932 Série A
MT 732 Turbo Série A
- Button 2 not engaged, the lever controls a hydraulic function.
- Pressing button 2, the lever controls another hydraulic function.
1
2
