Manitou A Series User Manual

2 - 73
FUNCTIONING
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
- Button 3 not engaged, buttons 4 and 5 control a hydraulic function.
- Pressing button 3, buttons 4 and 5 control another hydraulic function.
NOTE : Switch 6 enables the hydraulic function controlled by button 3 to be locked.
Indicator 7 lights up to show when it is in use.
13 - J
IB HEAD ELECTROVALVE + PREARRANGED HYDRAULIC
ATTACHMENT LOCKING
The addition of these two options enables the combining of several hydraulic functions.
14 - JIB HEAD ELECTROVALVE + ELECTRICAL JIB PROVISION
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
Adding these two options lets you combine several hydraulic functions. The hydraulic
attachment locking system can be added to this combination of options.
NOTE : In these combinations of options, the transmission cut-out button changes place
and is located at 5.
FUNCTIONING
- Without pressing buttons 1 and 2, buttons 3 and 4 control a hydraulic function.
- By pressing buttons 1 and 2, buttons 3 and 4 control another hydraulic function.
4
5
3
6
7
3
4
1
2
5
