32 - FRONT LIGHTS
A - Left front indicator.
B - Left front dipped headlight.
C - Left front main beam.
D - Left front sidelight.
E - Right front indicator.
F - Right front dipped headlight.
G - Right front main beam.
H - Right front sidelight.
33 - REAR LIGHTS
A - Left rear indicator.
B - Left rear stoplight.
C - Left tail light.
D - Left rear reverse light.
E - Left rear fog light.
F - Right rear fog light.
G - Right rear reverse light.
H - Right tail light.
I - Right rear stoplight.
J - Right rear indicator.
34 - REVOLVING LIGHT
The revolving light pivots for space-saving on the lift truck and can be detached to
prevent theft.
- Loosen nut 1 and remove the revolving light.
- Protect mounting 2 with cap 3.
35 - S
PIRIT LEVEL
Enables the operator to check that the lift truck is in the horizontal position.
A
B
C
F
G
E
A B C D E F G H I J
D
H
3
1
2
